General Product Overview
| Feature |
Specification |
| Product Type |
3-Core Hybrid Composite (3 Independent Shielded Units) |
| Primary Standard |
Nano-Scale Micro-Coaxial Hybrid Standards |
| Insulation Material |
Perfluoroalkoxy (PFA) |
| Outer Jacket Material |
Perfluoroalkoxy (PFA) – Black Color |
| Dielectric Strength |
500 Volts Alternating Current (AC) per minute |
| Operating Temperature Range |
-40 degrees Celsius to +80 degrees Celsius (-40 degrees Fahrenheit to +176 degrees Fahrenheit) |
| Finished Outside Diameter |
0.65 plus or minus 0.02 Millimeters |
| Optimal Preservation Period |
Two Months |
Multi-Component Construction Details
Shielded Sub-Cable Units (Quantity: 3)
Identification Colors: Black, Green, Blue
| Layer Component |
Material Specification |
Construction Design (n/mm) |
Diameter (mm) |
| 1. Inner Conductor |
Silver-plated Copper Alloy (42 AWG) |
7 x 0.025 |
0.075 plus or minus 0.01 |
| 2. Primary Insulation |
Perfluoroalkoxy (PFA) |
Nominal Thickness 0.06 |
0.195 plus or minus 0.02 |
| 3. Shielding Layer |
Silver-plated Copper Alloy |
Spiral Wrapped (0.02mm) |
0.235 plus or minus 0.02 |
| 4. Sub-Unit Jacket |
Perfluoroalkoxy (PFA) |
Nominal Thickness 0.02 |
0.275 plus or minus 0.02 |
Final Assembly Structure
| Layer Component |
Material Specification |
Nominal Thickness (mm) |
Final Diameter (mm) |
| Overall Outer Jacket |
Perfluoroalkoxy (PFA) – Black |
0.03 |
0.65 plus or minus 0.02 |
Electrical Performance Characteristics
| Performance Parameter |
Technical Value |
| Characteristic Impedance (at 1ns) |
50 plus or minus 5 Ohm |
| Typical Capacitance |
110 picofarads per meter |
| Center Conductor Resistance (@ 20°C) |
Maximum 7000 Ohm per kilometer |
| Insulation Resistance (@ 20°C) |
Minimum 1000 Ohm-kilometer |
| Dielectric Strength |
500 Volts (AC) per minute |
Professional Industry Advantages
-
High-Density Multi-Channel Integration: This cable packs three fully shielded 50 Ohm high-frequency transmission lines into a single 0.65 mm profile. This enables simultaneous multi-angle sensor feedback or RGB video signal delivery in the world’s most slender medical catheters and micro-probes.
-
Nano-Scale Precision Conductor: Utilizing a 7-strand silver-plated copper alloy (42 AWG) core provides a critical balance between high-fidelity signal conductivity and the tensile strength required for reliable performance in articulated robotic assemblies.
-
Premium PFA Dielectric Matrix: From internal insulation to the overall jacket, the use of high-grade Perfluoroalkoxy (PFA) ensures an exceptionally low dielectric constant and absolute resistance to chemicals, moisture, and extreme environmental stressors.
-
Zero-Crosstalk Shielding Design: Each internal core features its own independent silver-plated alloy spiral shield. This prevents electromagnetic coupling between the three channels and provides a total barrier against external interference, essential for high-sensitivity diagnostics.
-
Exceptional Pliability for Restricted Routing: With a total diameter smaller than a standard needle, this composite cable facilitates high-density functional routing in spaces previously only capable of supporting a single signal wire, empowering the next generation of micro-miniature industrial and medical equipment.
